Flush junction box 391x154x70mm - V70008

Pdf

V70008
System infrastructure / Enclosures and control units / Junction boxes / Flush mounting

Flush junction box 391x154x70mm
Flush mounting junction box with white cover and fixing screws. Dimensions 391x154x70 mm

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Shape
Rectangular
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Couplable
Yes
Equipped with
None
Diameter
0 mm
Length
391,00 mm
Width
416,00 mm
Depth
0,00 - 70,00 mm
Inner depth
70,00 mm
For number of electric fittings
0
Mounting switching equipment
Spread
With screws
No
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
Other
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
38
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Air tight
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
Special application
None

00. CE Marking - EU

43. UKCA mark - Great Britain

50. Product Environm. Profile

最小订单数量: 14 NR

条形码

Barcode Qty 1 NR
8007352082069
1 NR
41.6x17.9x7.5 [cm]
485.8 [g]
Barcode Qty 14 NR
8007352453562
14 NR
59x39x44 [cm]
7,700 [g]
Barcode Qty 224 NR
8007352453579
224 NR
120x80x190 [cm]
123,200 [g]
