Flush mounting box 12-14M light blue - V71320

V71320

Enclosures and mounting boxes / Flush mounting boxes / For masonry walls

Flush mounting box 12-14M light blue
12/14-module flush mounting box, (Glow Wire 650 °C), for masonry walls, light blue

  • Plenty of space of internal wiring
  • Wide range of accessories available: anti-mortar covers, coupling joints to create multiple series of boxes
  • Knockouts designed for the insertion of pipes with various cross-sections
  • Rack for fixing the dividing screen (patented)
  • Fixing lug of the support screws with zinc-plating treatment to prevent the thread from clogging during installation and favour screwing

产品状态
3 - Active

您可能也感兴趣

Class group
Connection devices
Class
Box/housing for built-in mounting in the
Mounting method
Flush mounted (plaster)
Shape
Rectangular
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Can be coupled
Yes
Equipped with
None
Diameter
0 mm
Length
134,00 mm
Width
180,00 mm
Depth
0,00 - 70,00 mm
Internal depth
50,00 mm
For number of electric fitting
14
Mounting switching equipment
Screwing
With screws
No
Housing feed-through by break-
Yes
Housing feed-through by seal m
No
Housing feed-through by nozzle
No
Housing feed-through by step m
No
For tube diameter
20/25 mm
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
14
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
None
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Wind proof
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
With nail lugs
No
Special application
None
最小订单数量: 20 NR

条形码

8007352117198
1 NR
19x14.4x7 [cm]
129.8 [g]
8007352122390
20 NR
59x38.5x24 [cm]
3,366 [g]
