Flush-mount box 4M f/hollow walls blue - V71704

Pdf
V71704

Enclosures and mounting boxes / Flush mounting boxes / For hollow walls

Flush-mount box 4M f/hollow walls blue
4-module mounting frame (GW 850 °C) for hollow walls, light blue

  • Suitable for several types of hollow walls (e.g. plasterboard, wood, plastic laminate or similar)
  • Preparation of the hole with a hollow cutter with a diameter of 68 mm. Hole centring plate incorporated into the back
  • Improved retention knockouts, designed for the insertion of pipes with various cross-sections (16, 20 or 25 mm) and metal fins for surface mounting the box on walls with a variable thickness of between 1 and 38 mm
  • Fixing lugs for support screws made of metal
  • Wide range of accessories available: accessories with a template function for tracing the hole, with joining function for mounting in series and installation on the inside of the wall; internal partitions; decorative covers

产品状态
3 - Active

您可能也感兴趣

Class group
Connection devices
Class
Box/housing for built-in mounting in the
Mounting method
Hollow wall
Shape
Rectangular
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Can be coupled
Yes
Equipped with
None
Diameter
0 mm
Length
72,50 mm
Width
133,80 mm
Depth
0,00 - 50,00 mm
Internal depth
50,00 mm
For number of electric fitting
4
Mounting switching equipment
Screwing
With screws
No
Housing feed-through by break-
Yes
Housing feed-through by seal m
No
Housing feed-through by nozzle
No
Housing feed-through by step m
No
For tube diameter
20/25 mm
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
14
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
None
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Wind proof
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
With nail lugs
No
Special application
None
最小订单数量: 5 NR

条形码

Barcode Qty 1 NR
8007352425705
1 NR
13.4x7.2x5 [cm]
38.64 [g]
Barcode Qty 5 NR
8007352425712
5 NR
13.4x7.2x25 [cm]
193.2 [g]
Barcode Qty 110 NR
8007352425729
110 NR
59x38.5x30 [cm]
5,090 [g]
