Vimar - V71706 - Flush-mount box 6-7M f/hollow walls blue

V71706
System infrastructure / Enclosures and control units / Connector block boxes / Flush mounting

Flush-mount box 6-7M f/hollow walls blue
6-7-module flush mounting box (GW 850 °C), for hollow walls, light blue

Suitable for several types of hollow walls (e.g. plasterboard, wood, plastic laminate or similar)
Preparation of the hole with a hollow cutter with a diameter of 68 mm. Hole centring plate incorporated into the back
Improved retention knockouts, designed for the insertion of pipes with various cross-sections (16, 20 or 25 mm) and metal fins for surface mounting the box on walls with a variable thickness of between 1 and 38 mm
Fixing lugs for support screws made of metal
Wide range of accessories available: accessories with a template function for tracing the hole, with joining function for mounting in series and installation on the inside of the wall; internal partitions; decorative covers

产品状态
3 - Active

视频

Tutorial ISOBOX EN

图纸

PNG DXF

Class group
Connection material (electrotechnical)

Class
Box/housing for built-in mounting in the wall/ceiling

Mounting method
Hollow wall

Shape
Rectangular

Construction type
Device connection box (round/square)

Model
Other

Provided with revolving ring
No

Couplable
Yes

Equipped with
None

Diameter
0 mm

Length
72,50 mm

Width
193,00 mm

Depth
0,00 - 50,00 mm

Inner depth
50,00 mm

For number of electric fittings
7

Mounting switching equipment
Screwing

With screws
No

Housing feed-through by break-out opening
Yes

Housing feed-through by seal membrane
No

Housing feed-through by nozzle
No

Housing feed-through by step membrane
No

For tube diameter
20/25 mm

Pipe locking
No

Pipe locking optional
No

Inlet from the rear
Yes

Number of inlets
18

Number of included spouts
0

Material
Plastic

Halogen free
Yes

Surface protection
Untreated

Colour
Blue

Degree of protection (IP)
IP00

Cover model
None

Transparent cover
No

Cover attachment
Screwed

Sealable
No

Circuit integrity
None

With screening
No

Air tight
No

Max. conductor cross section
0

Number of poles of the clamp
0

Clamp position fixed
No

Luminaire hook mounting
No

Nozzle
None

Special application
None

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

43. UKCA mark - Great Britain

96. Electrotechnical expert

最小订单数量: 5 NR

条形码

8007352425750

1 NR

19.3x7.2x5 [cm]

54.8 [g]

8007352425767

5 NR

19.3x7.2x25 [cm]

274 [g]

8007352425774

55 NR

59x38.5x24 [cm]

3,640 [g]

问题：	What is the code for the cover that can be installed on this mounting box?
回答：	Mounting box does not have any covers. The solution is to cover it with a mounting frame, cover plate or blank module.
