Taster 1P NO 10A carbon matt - 09008.CM

Pdf
09008.CM

Neve Up / Geräte / Steuerkontrolle

Taster 1P NO 10A carbon matt
Taste 1P NO 10 A 250 V~, Carbon Matt

Produktstatus
3 - Aktif

Das könnte Sie ebenfalls interessieren

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Taster
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Label space/information surface
Yes
Width of device
22,60 mm
Height of device
47,00 mm
Depth of device
35,90 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

29. QCERT - Kolumbien

29. QCERT - Kolumbien

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 50 NR

Barcode

Barcode Qty 1 NR
8007352657823
1 NR
4,1x2,8x5,3 [cm]
23,4 [g]
Barcode Qty 50 NR
8007352657830
50 NR
21,4x11,6x14,2 [cm]
1.270 [g]
Barcode Qty 500 NR
8007352657847
500 NR
57,5x22x29,5 [cm]
13.300 [g]
