Schalter 2P 32A carbon matt - 09020.CM

Pdf
09020.CM

Neve Up / Geräte / Steuerkontrolle

Schalter 2P 32A carbon matt

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Illumination
Yes
Function lighting
Other
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
32,00 A
Switching current for fluorescent lamps
0
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
Yes
Washing machine switch
Yes
Width of device
44,80 mm
Height of device
47,00 mm
Depth of device
43,60 mm
Built-in depth
30,50 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Min. depth of built-in installation box
35,00 mm
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE-Kennzeichnung - EU

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 10 NR

Barcode

Barcode Qty 1 NR
8007352703261
1 NR
5,1x4,3x5,3 [cm]
25 [g]
Barcode Qty 10 NR
8007352703278
10 NR
26,9x11,6x4,9 [cm]
279,2 [g]
Barcode Qty 200 NR
8007352703285
200 NR
47,5x27x29 [cm]
5.584 [g]
