09233
Neve Up / Geräte / Steckdosen - weitere Standards
Steckdose 2P 16A USA+EU ø4,8mm weiß
Steckdose 2P 16 A 250 V~, gepolter euro-amerikanischer Standard (parallel- und in Reihe-Flachstiften und Stiften ø 4,8 mm), weiß
Produktstatus
3 - Aktif
Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Steckdose
Model
Other
With built-in USB power supply
No
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
22,30 mm
Height of device
47,00 mm
Depth of device
39,50 mm
00. CE-Kennzeichnung - EU
10. EAC Eurasian Customs Union
37. Kennzeichnung - Marokko
Mindestbestellmenge: 50 NR
Barcode
8007352296794
1 NR
4,1x2,8x5,3 [cm]
25,93 [g]
8007352296800
50 NR
21,4x11,6x14,2 [cm]
1.382,73 [g]
8007352296817
500 NR
57,5x22,5x30 [cm]
14.442,67 [g]
