Ausschalter 1P 10AX weiß - 19000.B

Pdf
19000.B

Arké weiß / Geräte / Steuerkontrolle

Ausschalter 1P 10AX weiß
Ausschalter 1P 10 AX 250 V~, beleuchtbar, auswechselbare Wippe, weiß. Max. 100 W für Lampen mit integriertem Netzgerät (IEC 60669-1:2017)

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

19. NOM - Mexiko

29. QCERT - Kolumbien

36. ISI - Indien

37. Kennzeichnung - Marokko

43. UKCA-Marke Großbritannien

92. RoHS VAE

Mindestbestellmenge: 50 NR

Barcode

Barcode Qty 1 NR
8007352684768
1 NR
4,1x2,8x5,3 [cm]
24,6 [g]
Barcode Qty 50 NR
8007352684775
50 NR
21,4x11,6x14,2 [cm]
1.314,8 [g]
Barcode Qty 500 NR
8007352684782
500 NR
57,5x22,5x30 [cm]
14.300 [g]
Barcode Qty 10.500 NR
8007352704909
10.500 NR
80x120x103 [cm]
300.300 [g]
