Wechselschalter 1P 16AX antibakteriell g - 19005.AB

Pdf
19005.AB

Arké / Geräte / Steuerkontrolle

Wechselschalter 1P 16AX antibakteriell g
Wechselschalter 1P 16 AX 250 V~, beleuch

Produktstatus
3 - Aktif

Zeichnungen

Gruppe
Installationsschalterprogramme/Steckvorr
Klasse
Installationsschalter
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Other
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
36,80 mm
Built-in depth
25,00 mm

00. CE-Kennzeichnung - EU

10. EAC Eurasian Customs Union

43. UKCA-Marke Großbritannien

Mindestbestellmenge: 50 NR

Barcode

Barcode Qty 1 NR
8007352651821
1 NR
4,1x2,8x5,3 [cm]
31,36 [g]
Barcode Qty 50 NR
8007352651838
50 NR
21,6x11,6x14,3 [cm]
1.520 [g]
Barcode Qty 500 NR
8007352653634
500 NR
57,5x22,5x30 [cm]
15.680 [g]
