Axial 1P 10AX 2-way switch Metal - 19104.M

Pdf

19104.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Axial 1P 10AX 2-way switch Metal
Axial 1P 10 AX 250 V~ 2-way switch, lightable, replaceable button, Metal. Max 100 W for lamps with built-in power unit (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352684706
1 NR
5.1x2.8x5.3 [cm]
32.2 [g]
Barcode Qty 20 NR
8007352684713
20 NR
27x11.6x6 [cm]
709.4 [g]
