2P+E 16A Chinese SICURY outlet Metal - 19254.M

Pdf
19254.M

Arké Metal / Devices / Other standards socket outlets

2P+E 16A Chinese SICURY outlet Metal
2P+E 16 A 250 V~ SICURY socket outlet, Chinese standard, Metal - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Aluminium
RAL-number (similar)
9007
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
With miniature fuse
No
Special power supply
Other
Mounting method
Flush mounted (plaster)
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
38,50 mm
Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352596672
1 NR
5.1x4.3x5.3 [cm]
42.3 [g]
Barcode Qty 20 NR
8007352596689
20 NR
26.9x11.6x9 [cm]
927 [g]
