1P NC 10A push button white - 20010.B

Pdf

20010.B
Wiring devices / Traditional wiring devices / EIKON / Devices

1P NC 10A push button white
1P NC 10 A 250 V~ push button, lightable, replaceable button, white

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
36,15 mm

00. CE Marking - EU

14. TSE - Turkey

19. NOM - Mexico

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352316508
1 NR
4.1x2.8x5.3 [cm]
26.13 [g]
Barcode Qty 20 NR
8007352316515
20 NR
21.4x11.6x6 [cm]
588.33 [g]
Barcode Qty 300 NR
8007352644946
300 NR
37x28.5x25 [cm]
9,282 [g]
