20469.B
Eikon white / Systems / Access control system
NFC/RFID switch for Mifare white
NFC/RFID electronic transponder card reader for installation inside the room, compatible with Mifare Electronic Solutions for Hotels, vertical pocket, 1 relay output 10 A 230 V~ NO (NON SELV), 1 relay output 4 A 230 V~ NO (NON SELV), power supply 120-230 V~ 50/60 Hz, visible in darkness pocket lighting, white - 3 modules. Supplied without Mifare card (badge)
Product Status
3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Alarm installations, emergency call and
Class
Admittance control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
None
Reading strategy
Data medium
Signalling
Buzzer
Mounting method
Flush mounted (plaster)
Operating voltage at AC 50 Hz
120,00 - 230,00 v
Operating voltage at AC 60 Hz
120,00 - 230,00 v
Operation temperature
0 - 40 °C
Degree of protection (IP)
IP20
Colour
White
Width
67,30 mm
Height
49,00 mm
Depth
50,00 mm
Minimum order quantity: 1 NR
Barcode
8007352623903
1 NR
5.2x5.7x7.6 [cm]
97.4 [g]
8007352623910
5 NR
21.4x11.6x6 [cm]
543.2 [g]
Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see conditions of use.
