1P NO 10A push button Vintage satin gold - 22008.88

Pdf
Vimar - 22008.88 - 1P NO 10A push button Vintage satin gold
Vimar - 22008.88 - 1P NO 10A push button Vintage satin gold
22008.88

Eikon EXÉ / Devices / Vintage and Flat devices

1P NO 10A push button Vintage satin gold
1P NO 10 A 250 V~ Vintage push button, satin-finish gold

Product Status
3 - Active

Drawings

view encumbered art. 22008.88
PNG DXF
rear view art. 22008.88
PNG DXF
3D view art. 22008.88
PNG DXF
Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Nominal voltage
230 v
Rated current
10,00 A
With lighting
No
With signal lamp
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Metal
Material quality
Brass
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Gold
RAL-number (similar)
1035
Transparent
No
Label space/information surface
Yes
Width of device
22,30 mm
Height of device
44,80 mm
Depth of device
54,60 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352655379
1 NR
5.1x6.5x2.7 [cm]
29.7 [g]
Barcode Qty 10 NR
8007352655386
10 NR
14.5x11x7.4 [cm]
347.2 [g]
