Toma 2P 10A P10 axial blanco - 01022.B

Pdf
01022.B

Clavijas y tomas de corriente / Mille / Tomas salida axial

Toma 2P 10A P10 axial blanco
Toma SICURY 2P 10 A 250 V~ estándar italiano tipo P10, blanco

Estado producto
3 - Activo

Podría interesarte también

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P10
With signal lamp
No
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
0
Number of socket outlets switchable
0
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9016
Metallic colour
No
Transparent
No
Lockable
Yes
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
With miniature fuse
No
Special power supply
No special power supply
Mounting method
Other
Type of fastening
Mounting with screw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
10 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Width of device
40,00 mm
Height of device
46,00 mm
Depth of device
18,00 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

Cant. mínima de pedido: 100 NR

Código de barras

Barcode Qty 1 NR
8007352035331
1 NR
4x6,6x1,8 [cm]
26,13 [g]
Barcode Qty 10 NR
8007352325760
10 NR
20x15x5 [cm]
263,6 [g]
Barcode Qty 100 NR
8007352009943
100 NR
28,5x26x23,5 [cm]
2.819,27 [g]

Compartir

Codice QR scheda articolo

Legal

Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
