06200
Mascot / Dispositivos / Dispositivos de mando básicos
Interruptor 1P 10AX marfil
Interruptor 1P 10 AX 250 V~, tecla grande, marfil
Estado producto
2 - Será eliminado
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Mounting with claw
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
80,00 mm
Height of device
80,00 mm
Depth of device
36,00 mm
Cant. mínima de pedido: 20 NR
Código de barras
8007352094253
1 NR
8x8x3,6 [cm]
54,67 [g]
8007352094260
20 NR
29,5x24,8x8,7 [cm]
1.301 [g]
Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
