Interruptor cruzado 1P 10AX marfil - 06212

Pdf
06212

Mascot / Dispositivos / Dispositivos de mando básicos

Interruptor cruzado 1P 10AX marfil
Interruptor cruzado 1P 10 AX 250 V~, tecla grande, marfil

Estado producto
2 - Será eliminado

Podría interesarte también

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Mounting with claw
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
80,00 mm
Height of device
80,00 mm
Depth of device
36,00 mm

00. Marcado CE - UE

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352094376
1 NR
8x8x3,6 [cm]
66,4 [g]
Barcode Qty 20 NR
8007352095557
20 NR
31x24,8x8,7 [cm]
1.561,07 [g]
