Conmutador 1P 10AX+toma P17/11 marfil - 06690

Pdf
06690

Mascot / Dispositivos / Dispositivos de mando - otras funciones

Conmutador 1P 10AX+toma P17/11 marfil
Conmutador 1P 10 AX 250 V~ + toma Bpresa SICURY 2P+T 16 A 250 V~ estándar italiano tipo P17/11, marfil

Estado producto
2 - Será eliminado

Podría interesarte también

Class group
Domestic switching devices
Class
Combination switch/wall socket outlet
Type of switch
Two-way switch
Type of socket outlet
Other
Number of socket outlets
1
Method of operation
Rocker/button
Mounting direction
Horizontal and vertical
Type of fastening
Mounting with claw
With lighting
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Transparent
No
Suitable for degree of protection (IP)
IP20
Nominal voltage
250 v
Nominal current socket outlet
16 A
Rated current
16 A
Over voltage protection
No
Fault current protection
No
Width of device
80,00 mm
Height of device
80,00 mm
Depth of device
36 mm

00. Marcado CE - UE

37. Marcado - Marruecos

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352095472
1 NR
8x8x3,6 [cm]
74,31 [g]
Barcode Qty 20 NR
8007352098497
20 NR
31x24,8x8,7 [cm]
1.708,87 [g]

Compartir

Codice QR scheda articolo

Legal

Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
