Interruptor cruzado 1P 16AX - 08013

Pdf
08013

8000 / Dispositivos / Dispositivos de mando básicos

Interruptor cruzado 1P 16AX
Interruptor cruzado 1P 16 AX 250 V~. Máx

Estado producto
3 - Activo

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,00 mm
Height of device
50,10 mm
Depth of device
38,00 mm
Built-in depth
27,00 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 50 NR

Código de barras

Barcode Qty 1 NR
8007352013803
1 NR
4,1x2,8x5,3 [cm]
31,2 [g]
Barcode Qty 50 NR
8007352007352
50 NR
21,4x11,6x14,2 [cm]
1.649,13 [g]
Barcode Qty 500 NR
8007352641501
500 NR
57,5x22,5x30 [cm]
16.990 [g]

Compartir

Codice QR scheda articolo

Legal

Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
