Interruptor 2P 10AX +llave - 08381

Pdf
08381

8000 / Dispositivos / Dispositivos de mando - otras funciones

Interruptor 2P 10AX +llave
Interruptor de llave 2P 10 AX 250 V~. Má

Estado producto
3 - Activo

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Key
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
9001
Label space/information surface
Yes
Illumination
No
Function lighting
Other
Type of lighting
Other
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Height of device
45,00 mm
Depth of device
43,00 mm
Built-in depth
33,50 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

14. TSE - Turquía

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352014862
1 NR
6x2,8x5,3 [cm]
48,73 [g]
Barcode Qty 20 NR
8007352016873
20 NR
28,1x13,1x6 [cm]
1.059,53 [g]

Compartir

Codice QR scheda articolo

Legal

Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
