Toma 2P+T 16A P30 - 08409

Pdf
08409

8000 / Dispositivos / Tomas estándar italiano

Toma 2P+T 16A P30
Toma SICURY 2P+T 16 A 250 V~ estándar italiano tipo P30 (contactos de tierra laterales y central) - 2 módulos especiales

Estado producto
3 - Activo

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P30
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Height of device
45,00 mm
Depth of device
39,50 mm

00. Marcado CE - UE

00. Marcado CE - UE

07. INGCER - Chile

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352090460
1 NR
5,1x4,3x5,3 [cm]
52,7 [g]
Barcode Qty 20 NR
8007352090477
20 NR
26,9x11,6x9 [cm]
1.135,27 [g]
Barcode Qty 240 NR
8007352641723
240 NR
38x28,5x35,5 [cm]
14.148 [g]
