Toma 2P+T 16A P30 interbl.+MT C16 - 08443

Pdf
08443

8000 / Dispositivos / Tomas protegidas

Toma 2P+T 16A P30 interbl.+MT C16
Toma SICURY 2P+T 16 A 250 V~ estándar italiano tipo P30 (contactos de tierra laterales y central), interbloqueada con interruptor automático magnetotérmico 1P+N C 16, alimentación 230 V~ 50 Hz, poder de corte 3000 A - 3 módulos especiales

Estado producto
2 - Será eliminado

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P30
With built-in USB power supply
No
Number of units
2
Number of modules (module system)
3
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Special power supply
No special power supply
Mounting method
Flush mounted (plaster)
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
Yes
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
230 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Height of device
45,00 mm
Depth of device
56,30 mm

00. Marcado CE - UE

37. Marcado - Marruecos

Cant. mínima de pedido: 5 NR

Código de barras

Barcode Qty 1 NR
8007352112940
1 NR
5,2x5,7x7,6 [cm]
121,4 [g]
Barcode Qty 5 NR
8007352112957
5 NR
21,4x11,6x6 [cm]
664,87 [g]

Compartir

Codice QR scheda articolo

Legal

Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
