Interruptor 2P 20AX carbon matt - 09016.G.CM

Pdf
09016.G.CM

Neve Up / Dispositivos / Dispositivos de mando básicos

Interruptor 2P 20AX carbon matt
Interruptor 2P 20 AX 250 V~, difusor neutro iluminable, carbon matt. Máx 250 W para lámparas con alimentador integrado (IEC 60669-1:2017)

Estado producto
3 - Activo

Dibujos

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
No
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Label space/information surface
No
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 v
Rated current
20,00 A
Switching current for fluorescent lamps
20
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Width of device
22,30 mm
Height of device
47,00 mm
Depth of device
38,20 mm
Built-in depth
25,40 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. Marcado CE - UE

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 50 NR

Código de barras

Barcode Qty 1 NR
8007352712645
1 NR
4,1x2,8x5,3 [cm]
33,39 [g]
Barcode Qty 50 NR
8007352712652
50 NR
21,4x11,6x14,2 [cm]
1.679,5 [g]
Barcode Qty 500 NR
8007352712669
500 NR
57,5x22,5x30 [cm]
17.295 [g]
