09066
Series residenciales / Series resid. tradicionales / NEVE UP / Dispositivos
Dos puls.independ. 1P NO+NO 10A blanco
Estado producto
3 - Activo
Dibujos
Class group
Domestic switching devices
Domestic switching devices
Class
Push button
Push button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Model
Other
Other
Operating method
Push button
Push button
Number of contacts as normally closed contact
0
0
Number of contacts as normally open contact
2
2
Number of contacts as change-over contact
0
0
Number of revolving contacts
0
0
Contactless type
No
No
Number of rockers
2
2
Number of modules (module system)
1
1
Number of poles
1
1
Nominal voltage
250 V
250 V
Rated current
10,00 A
10,00 A
With lighting
No
No
With light source
No
No
With signal lamp
No
No
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Mounting method
Built-in
Built-in
Type of fastening
Engage (snap)
Engage (snap)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Si
Si
Anti-bacterial treatment
No
No
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
White
White
RAL-number (similar)
9003
9003
Transparent
No
No
Label space/information surface
Si
Si
Imprint
None
None
Suitable for degree of protection (IP)
IP40
IP40
Impact strength
Other
Other
Device width
22,30 mm
22,30 mm
Device height
47,00 mm
47,00 mm
Device depth
38,50 mm
38,50 mm
Min. depth of built-in installation box
35,00 mm
35,00 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
00. Marcado CE - UE
37. Marcado - Marruecos
37. Marcado - Marruecos
Cant. mínima de pedido: 20 NR
Código de barras
8007352726611
1 NR
4,1x2,8x5,3 [cm]
31,4 [g]
8007352726628
20 NR
21,4x11,6x6 [cm]
682,84 [g]
8007352726635
200 NR
30,5x25,5x22,5 [cm]
7.146 [g]
