Mecanismo conmutador 1P 10AX bornes aut. - 14004.FX.0

Pdf
14004.FX.0

Plana / Dispositivos / Dispositivos de mando básicos

Mecanismo conmutador 1P 10AX bornes aut.
Mecanismo conmutador 1P 10 AX 250 V~, bo

Estado producto
3 - Activo

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
Green
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Push-in clamp
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
40,50 mm
Built-in depth
26,10 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 50 NR

Código de barras

Barcode Qty 1 NR
8007352513891
1 NR
5,1x2,8x5,3 [cm]
24,3 [g]
Barcode Qty 50 NR
8007352513907
50 NR
27x15x12 [cm]
1.356 [g]
