14020
Series residenciales / Series resid. tradicionales / PLANA / Dispositivos
Interruptor 2P 32A blanco
Estado producto
3 - Activo
Dibujos
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Switch 2-pole
Switch 2-pole
Operating method
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
2
2
Push button switch
Si
Si
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Si
Si
Anti-bacterial treatment
No
No
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
White
White
RAL-number (similar)
9003
9003
Lighting
Yes
Yes
Function lighting
Other
Other
Type of lighting
LED exchangeable
LED exchangeable
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
250 V
250 V
Rated current
32,00 A
32,00 A
Switching current for fluorescent lamps
0
0
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Heating switch
Si
Si
Washing machine switch
Si
Si
Device width
44,80 mm
44,80 mm
Device height
49,00 mm
49,00 mm
Device depth
43,60 mm
43,60 mm
Built-in depth
29,50 mm
29,50 mm
Min. depth of built-in installation box
35,00 mm
35,00 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
Cant. mínima de pedido: 10 NR
Código de barras
8007352703209
1 NR
5,1x4,3x5,3 [cm]
51,26 [g]
8007352703216
10 NR
26,9x11,6x4,9 [cm]
586,75 [g]
8007352703223
200 NR
47,5x27x29 [cm]
12.420 [g]
