Toma SICURY 2P+T 16A alemán+tapa Silver - 14208.C.SL

Pdf
14208.C.SL

Plana Silver / Dispositivos / Tomas - otros estándares

Toma SICURY 2P+T 16A alemán+tapa Silver
Toma de corriente SICURY 2P+T 16 A 250 V~ estándar alemán con tapa, iluminable, Silver - 2 módulos

Estado producto
3 - Activo

Dibujos

Class group
Domestic switching devices
Class
Socket outlet
Model
Protective contact (SCHUKO)
With built-in USB power supply
No
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
Yes
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Silver
RAL-number (similar)
9006
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
38,90 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

Cant. mínima de pedido: 10 NR

Código de barras

Barcode Qty 1 NR
8007352431669
1 NR
5,1x4,3x5,3 [cm]
52,7 [g]
Barcode Qty 10 NR
8007352431676
10 NR
26,9x11,6x4,9 [cm]
588,5 [g]
Barcode Qty 200 NR
8007352646650
200 NR
47,5x27x29 [cm]
12.280 [g]
