Piloto difusor rojo grisCódigo 16431.R

Descargar como PDFPDF
Immagine 16431.R
Immagine 16431.R
16431.R
Series residenciales / Series resid. tradicionales / IDEA / Dispositivos
Piloto difusor rojo gris
Piloto para lámpara ø 6,3x28 mm o 7x31 mm, difusor rojo, gris. Suministrado sin lámpara
Estado producto
3 - Activo
Class group
Domestic switching devices
Class
Information light signal for domestic switching devices
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Lamp holder
Other
With light source
No
Lamp type
Other
With flashlight
No
With fixed symbol/imprint
No
With exchangeable symbol
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Si
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
3001
Transparent
No
Colour light source
Red
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352002609
1 NR
5,1x2,8x5,3 [cm]
31,4 [g]
Barcode Qty 20 NR
8007352000766
20 NR
27x11,6x6 [cm]
696,93 [g]
Barcode Qty 120 NR
8007352654396
120 NR
37,5x30x13,5 [cm]
4.536 [g]
