16895
Infraestructura de instalación / Cajas y centralitas / Cajas de empotrar / Accesorios de instalación
Caja empotrable
Caja empotrable, azul. Dimensiones 225,5x127,5x70 mm
Estado producto
2 - Será eliminado
Class group
Electrical installation, isolation and connection material
Electrical installation, isolation and connection material
Class
Box/housing for built-in mounting in the wall/ceiling
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Flush-mounted
Shape
Rectangular
Rectangular
Construction type
Device connection box (round/square)
Device connection box (round/square)
Model
Other
Other
Provided with revolving ring
No
No
Couplable
No
No
Equipped with
None
None
Diameter
32 mm
32 mm
Length
239,00 mm
239,00 mm
Width
140,00 mm
140,00 mm
Depth
0,00 - 70,00 mm
0,00 - 70,00 mm
Inner depth
68,00 mm
68,00 mm
For number of device inserts
1
1
Mounting switching equipment
Screwing
Screwing
With screws
No
No
Housing feed-through by break-out opening
Si
Si
Housing feed-through by seal membrane
No
No
Housing feed-through by nozzle
No
No
Housing feed-through by step membrane
No
No
For tube diameter
20/25 mm
20/25 mm
Suitable for cable diameter
0 - 32 mm
0 - 32 mm
Pipe locking
No
No
Pipe locking optional
No
No
Inlet from the rear
Si
Si
Number of inlets
14
14
Number of included spouts
0
0
Material
Plastic
Plastic
Halogen free
Si
Si
Surface protection
Untreated
Untreated
Colour
Blue
Blue
Degree of protection (IP)
IP20
IP20
Cover model
None
None
Transparent cover
No
No
Cover attachment
Screwed
Screwed
Sealable
No
No
With screening
No
No
Airtight
No
No
Max. conductor cross section
0 mm2
0 mm2
Number of poles of the clamp
0
0
Clamp position fixed
No
No
Luminaire hook mounting
No
No
Nozzle
None
None
Special application
None
None
Cant. mínima de pedido: 25 NR
Código de barras
8007352082984
1 NR
22x12,7x7 [cm]
163,37 [g]
8007352115514
25 NR
59x38,5x30 [cm]
4.910,67 [g]
