Mecanismo interruptor 1P 10AX - 19000.0

Pdf
19000.0

Arké / Dispositivos / Dispositivos de mando básicos

Mecanismo interruptor 1P 10AX
Mecanismo interruptor 1P 10 AX 250 V~, iluminable, a completar con tecla 1-2-3 módulos. Máx 100 W para lámparas con alimentador integrado (IEC 60669-1:2017)

Estado producto
3 - Activo

Dibujos

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Blue
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

00. Marcado CE - UE

10. EAC Eurasian Customs Union

19. NOM - México

29. QCERT - Colombia

36. ISI - India

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352684911
1 NR
4,1x2,8x5,3 [cm]
22,7 [g]
Barcode Qty 20 NR
8007352684928
20 NR
21,4x11,6x6 [cm]
512,7 [g]
Barcode Qty 200 NR
8007352684935
200 NR
30,5x25,5x22,5 [cm]
5.127 [g]
