Mecanismo variador conectado IoT 120VCódigo 19595.0.120
- 19595.0.120
- Series residenciales / Series resid. View Wireless / ARKÉ / Dispositivos
- Mecanismo variador conectado IoT 120V
- Estado producto
- 3 - Activo
Instrucciones, Manuales, Documentación
- Hoja de instrucciones multilingüe Light (1141 kb)
- Foglio istruzioni multilingua Full (670 kb)
- Feuille d’instructions multilangues Full (671 kb)
- Hoja de instrucciones multilingüe Full (668 kb)
- Full Multilanguage instructions sheet (664 kb)
- Πολυγλωσσικό φύλλο οδηγιών Full (822 kb)
- Mehrsprachig-Gebrauchsinformation Full (668 kb)
- ورقة الإرشادات Full (737 kb)
- Manuale app View Wireless (19698 kb)
- Manuel appli View Wireless (42466 kb)
- Manual app View Wireless (42466 kb)
- Manual View Wireless app (42593 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (42754 kb)
- Installationsanleitung View Wireless (42520 kb)
Dibujos
Class group
Domestic switching devices
Domestic switching devices
Class
Installation switch
Installation switch
Wiring system
Other
Other
Operating method
Rocker/button
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Modular device for domestic switching devices
Number of modules (module system)
1
1
Push button switch
Si
Si
Number of rockers
1
1
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Engage (snap)
Engage (snap)
With mounting plate
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
No
No
Anti-bacterial treatment
No
No
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Blue
Blue
RAL-number (similar)
7015
7015
Label space/information surface
No
No
Lighting
Yes
Yes
Function lighting
Other
Other
Type of lighting
LED not exchangeable
LED not exchangeable
Suitable for degree of protection (IP)
IP40
IP40
Nominal voltage
120 V
120 V
Monitoring contact
No
No
Connection type
Screwed terminal
Screwed terminal
Heating switch
No
No
Washing machine switch
No
No
Device width
22,20 mm
22,20 mm
Device height
49,00 mm
49,00 mm
Device depth
46,40 mm
46,40 mm
Built-in depth
36,50 mm
36,50 mm
Min. depth of built-in installation box
41,00 mm
41,00 mm
Compatible with Apple HomeKit
Si
Si
Compatible with Google Assistant
Si
Si
Compatible with Amazon Alexa
Si
Si
IFTTT support available
Si
Si
Cant. mínima de pedido: 1 NR
Código de barras

8007352707696
1 NR
5,2x3,5x5,3 [cm]
49 [g]

8007352707702
60 NR
27x23x12,5 [cm]
3.130 [g]
Compartir
Legal
Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
