Interruptor 1P 10AX bornes aut. Next - 20000.FX.N

Pdf
20000.FX.N

Eikon Next / Dispositivos / Dispositivos de mando básicos

Interruptor 1P 10AX bornes aut. Next
Interruptor 1P 10 AX 250 V~, bornes de cableado rápido, iluminable, tecla sustituible, Next. máx 100 W para lámparas con balasto integrado (IEC 60669-1:2017)

Estado producto
3 - Activo

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
10,00 A
Switching current for fluorescent lamps
10
Feedback-signal contact
No
Connection type
Push-in clamp
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
38,30 mm
Built-in depth
26,90 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 1 NR

Código de barras

Barcode Qty 1 NR
8007352630246
1 NR
5,1x2,8x5,3 [cm]
25,6 [g]
Barcode Qty 50 NR
8007352630253
50 NR
27x15x12 [cm]
1.368 [g]
