Interruptor 1P 16AX 2M Next - 20001.2.N

Pdf
20001.2.N

Eikon Next / Dispositivos / Dispositivos de mando básicos

Interruptor 1P 16AX 2M Next
Interruptor 1P 16 AX 250 V~, iluminable, tecla intercambiable, Next - 2 módulos. Máx 200 W para lámparas con balasto integrado

Estado producto
3 - Activo

Dibujos

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
36,10 mm
Built-in depth
25,00 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

13. SNI - Indonesia

14. TSE - Turquía

19. NOM - México

29. QCERT - Colombia

31. TISI - Tailandia

36. ISI - India

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

92. RoHS EAU

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352285453
1 NR
5,1x4,3x5,3 [cm]
34 [g]
Barcode Qty 20 NR
8007352285460
20 NR
26,9x11,6x9 [cm]
761,73 [g]
Barcode Qty 240 NR
8007352643536
240 NR
38x28,5x35,5 [cm]
9.684 [g]
