Interruptor cruzado axial 1P 16AX Next - 20113.N

Pdf
20113.N

Eikon Next / Dispositivos / Dispositivos de mando básicos

Interruptor cruzado axial 1P 16AX Next
Interruptor cruzado axial 1P 16 AX 250 V~, iluminable, tecla sustituible, Next. Máx 200 W para lámparas con balasto integrado

Estado producto
3 - Activo

Podría interesarte también

Dibujos

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
44,00 mm
Built-in depth
34,50 mm

00. Marcado CE - UE

10. EAC Eurasian Customs Union

19. NOM - México

29. QCERT - Colombia

31. TISI - Tailandia

36. ISI - India

37. Marcado - Marruecos

43. Marca UKCA - Gran Bretaña

Cant. mínima de pedido: 20 NR

Código de barras

Barcode Qty 1 NR
8007352460225
1 NR
5,1x2,8x5,3 [cm]
37,1 [g]
Barcode Qty 20 NR
8007352460232
20 NR
27x11,6x6 [cm]
811,9 [g]
Barcode Qty 120 NR
8007352651395
120 NR
37,5x30x13,5 [cm]
5.220 [g]
