30203.C
Series residenciales / Series resid. tradicionales / LINEA / Dispositivos
Toma 2P+T 16A P17/11 cáñamo
Toma de corriente SICURY 2P+T 16 A 250 V~ estándar italiano tipo P17/11, hueso
Estado producto
3 - Activo
Dibujos
Class group
Domestic switching devices
Domestic switching devices
Class
Socket outlet
Socket outlet
Model
Italian type P17/11
Italian type P17/11
Number of active contacts (round)
0
0
Number of active contacts (flat)
0
0
Number of active contacts (square)
0
0
With signal lamp
No
No
Number of ports USB-A
0
0
Number of ports USB-C
0
0
Number of socket outlets
1
1
Number of modules (module system)
1
1
Number of socket outlets switchable
0
0
Number of phases
1
1
Imprint/indication
Other
Other
Connection type
Screwed terminal
Screwed terminal
With hinged lid
No
No
With enhanced contact protection
Si
Si
Label space/information surface
No
No
Colour
Beige
Beige
RAL-number (similar)
7032
7032
Metallic colour
No
No
Transparent
No
No
Lockable
No
No
Eject-mechanism
No
No
Insulated mounting
No
No
With function lighting
No
No
With orientation lighting
No
No
Overvoltage protection
No
No
Fault current protection
No
No
With miniature fuse
No
No
Special power supply
None
None
Mounting method
Flush-mounted
Flush-mounted
Type of fastening
Snap mounting (engagement)
Snap mounting (engagement)
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Si
Si
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Anti-bacterial treatment
No
No
With loop through function
No
No
With on/off switch
No
No
Rotated central insert
No
No
Nominal current
16 A
16 A
Nominal voltage
250 V
250 V
Frequency
50,00 - 60,00 HZ
50,00 - 60,00 HZ
Rated fault current
0 mA
0 mA
Suitable for degree of protection (IP)
IP20
IP20
Impact strength
Other
Other
Device width
22,30 mm
22,30 mm
Device height
52,80 mm
52,80 mm
Device depth
33,80 mm
33,80 mm
Compatible with Apple HomeKit
No
No
Compatible with Amazon Alexa
No
No
Compatible with Google Assistant
No
No
IFTTT support available
No
No
With Wi-Fi signal repeater
No
No
With built-in bluetooth speaker
No
No
For heavy conditions according to VDE
No
No
00. Marcado CE - UE
37. Marcado - Marruecos
37. Marcado - Marruecos
50. Product Environm. Profile
Cant. mínima de pedido: 50 NR
Código de barras
8007352687165
1 NR
3,6x2,7x5,6 [cm]
31,9 [g]
8007352687189
50 NR
20x14,7x12,4 [cm]
1.714 [g]
8007352687196
300 NR
47x22x27,5 [cm]
10.682 [g]
8007352750012
6.300 NR
120x80x105 [cm]
224.317,8 [g]
