V72006
Cajas / Cajas de derivación empotrables / Para paredes huecas
Caja derivación pared hueca205x164x73,5m
Cajas de derivación de empotrar para paredes huecas con tapa blanca y tornillos defijación. Dimensiones 205x164x73,5 mm
Estado producto
3 - Activo
Class group
Connection devices
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush mounted (plaster)
Shape
Rectangular
Construction type
Cable junction box
Model
Other
Provided with revolving ring
No
Connectable
Yes
Equipped with
None
Diameter
0 mm
Length
205,00 mm
Width
205,00 mm
Depth
0,00 - 73,50 mm
Internal depth
73,50 mm
For number of electric fittings
0
Mounting switching equipment
Spread
With screws
Yes
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
Other
Pipe locking
Yes
Pipe locking optional
Yes
Inlet from the rear
Yes
Number of inlets
14
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP20
Cover model
Blind cover
Transparent cover
No
Cover attachment
Screwed
Sealable
No
With screening
No
Air tight
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
With nail lugs
Yes
Special application
None
Cant. mínima de pedido: 7 NR
Código de barras
8007352589919
1 NR
22,8x22,5x7,6 [cm]
351 [g]
8007352589926
7 NR
59,5x26,5x41,5 [cm]
2.915 [g]
Vimar se reserva el derecho de cambiar en cualquier momento y sin previo aviso las características de los productos reportados. La instalación debe ser realizada por personal cualificado cumpliendo con las disposiciones en vigor que regulan el montaje del material eléctrico en el país donde se instalen los productos. Para las condiciones de uso de la información de la ficha del producto, consulte Condiciones de uso.
