Binary input 4-channel 120/230V KNX - 01510

Pdf
Vimar - 01510 - Binary input 4-channel 120/230V KNX
Vimar - 01510 - Binary input 4-channel 120/230V KNX

01510
Smart systems&products / KNX / Shared components / DIN devices

Binary input 4-channel 120/230V KNX
4-channel digital input device, programmable for NO, NC and 120-230 V~ contacts, KNX standard, installation on DIN rail (60715 TH35), occupies 2 17,5 mm modules

产品状态
3 - Active

Class group
Installation bus systems
Class
I/O device for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Width in number of modular spacings
2
With bus connection
Yes
LED controlling
No
With LED indication
Yes
Local operation/hand operation
Yes
Suitable for C-load
Yes
With switch function
No
External signal voltage necessary
No
Different phases connectable
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352383555
1 NR
14.2x6.7x5.9 [cm]
109 [g]
