By-alarm Plus IR curtain PET imm.detect. - 01740

Pdf

Vimar - 01740 - By-alarm Plus IR curtain PET imm.detect.

01740
Safety / By-alarm Plus / Surface mounting components / Non-modular components

By-alarm Plus IR curtain PET imm.detect.
By-alarm Plus IR curtain-effect detector to protect entrances and openings such as doors, windows, covered terraces, corridors and French doors, adjustable-range detection with lens up to 2 m or 5 m, PET immune, anti-masking function, 9.5- 18V DC 20 mA power supply, 1 NO or NC 28V DC 0.1A relay output, surface mounting, for outdoor use

产品状态
3 - Active

单, 说明书, 文档

Class group
Alarm installations, emergency call and signalling

Class
Movement detector for danger detection system

Type of messaging
Passive infrared

Mounting method
Surface mounting

Characteristic
Curtain

Cover monitoring
Yes

Radio system
Yes

00. CE Marking - EU

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352667280

1 NR

20.5x8.5x6 [cm]

293.47 [g]

8007352672369

37 NR

51x34x26.5 [cm]

9,357 [g]

8007352671553

48 NR

51x35x35 [cm]

11,568 [g]
