Safety / By-alarm Plus / Surface mounting components / Non-modular components
By-alarm Plus IR IP65 60m surf.barrier
By-alarm Plus barrier kit consisting of TX/RX active infrared pair (AIR) with outdoor range of 60 metres, with 4 selectable channels to create a column barrier comprising several stacked detectors, IP65, 1 NO/NC 28 VDC 0.2A relay output for alarm, 1 NC 28 VDC 0.2A relay output to prevent false alarms due to adverse weather conditions (fog, rain, snow), 10.5-28 VDC power supply with 48 mA 12V surface, pole, column mounting, for outdoor use
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Movement detector for danger detection system
Movement detector for danger detection system
Type of messaging
Passive infrared
Passive infrared
Mounting method
Surface mounting
Surface mounting
Operating current
48,00 mA
48,00 mA
Monitoring radius
60 m
60 m
Characteristic
Distance
Distance
Height
170,00 mm
170,00 mm
Width
65,00 mm
65,00 mm
Depth
69,50 mm
69,50 mm
Colour
White
White
VdS class
None
None
最小订单数量: 1 NR
条形码
8007352767393
1 NR
20.8x16.5x9.6 [cm]
935 [g]
