LED RGB driver 230V 50Hz 12-24Vdc - 01876

Pdf
Vimar - 01876 - LED RGB driver 230V 50Hz 12-24Vdc
Vimar - 01876 - LED RGB driver 230V 50Hz 12-24Vdc

01876
Wiring devices / Traditional wiring devices / Shared components / Accessories

LED RGB driver 230V 50Hz 12-24Vdc
Multivoltage driver 230 V~ 50 Hz for RGB LED modules 12/24 Vdc, dimmable with RGB and FADING-SHOW dimmers

产品状态
3 - Active

Class group
Light control
Class
LED driver
Suitable for outdoor use
No
Housing
Plastic housing
Suitable for constant current
No
Suitable for constant voltage
Yes
Output voltage
12 - 24 V
Output current
0 - 1.700 mA
Suitable for DC-voltage (primary side)
No
Output power
24,00 - 24,01 W
Degree of protection (IP)
IP20
Protection class according to IEC 61140
II
Length
36,60 mm
Width
218,00 mm
Height
60,50 mm
Diameter
0 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352468757
1 NR
26.9x11.6x4.9 [cm]
321.1 [g]

分享

Codice QR scheda articolo

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。 安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件，请参阅 使用条件。
