LED RGB driver 120V 60Hz 12-24Vdc - 01876.120

Pdf
Vimar - 01876.120 - LED RGB driver 120V 60Hz 12-24Vdc
Vimar - 01876.120 - LED RGB driver 120V 60Hz 12-24Vdc

01876.120
Wiring devices / Traditional wiring devices / Shared components / Accessories

LED RGB driver 120V 60Hz 12-24Vdc
Multivoltage driver 120 V~ 60 Hz for RGB LED modules 12/24 Vdc, dimmable with RGB and FADING-SHOW dimmers

产品状态
2 - Will be discontinued

Class group
Light control
Class
LED driver
Suitable for outdoor use
No
Housing
Plastic housing
Suitable for constant current
No
Suitable for constant voltage
Yes
Output voltage
12 - 24 V
Output current
0 - 1.700 mA
Suitable for DC-voltage (primary side)
No
Output power
24,00 - 24,01 W
Degree of protection (IP)
IP20
Protection class according to IEC 61140
II
Length
36,60 mm
Width
218,00 mm
Height
60,50 mm
Diameter
0 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352482357
1 NR
26.9x11.6x4.9 [cm]
321.4 [g]
