Hi-Fi amplifier 2outs 8ohm 10-10W - 01901

Pdf
Vimar - 01901 - Hi-Fi amplifier 2outs 8ohm 10-10W
Foto gallery #1
Foto gallery #2
Vimar - 01901 - Hi-Fi amplifier 2outs 8ohm 10-10W

01901
Smart systems&products / By-me Plus / Shared components / DIN devices

Hi-Fi amplifier 2outs 8ohm 10-10W
Stereo amplifier, 2 outputs for speakers 8 ohm 10+10 W, power supply 110-230 V 50-60 Hz, built-in line terminator, installation on DIN rail (60715 TH35), occupies 6 17,5 mm modules

产品状态
3 - Active

Class group
Installation bus systems
Class
Analogue actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Mounting method
Other
Width in number of modular spacings
6
Model
Base module
With LED indication
Yes
With bus connection
Yes
Number of outputs
2
Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352400078
1 NR
11.7x10.8x7.1 [cm]
280.84 [g]
问题： Can I connect just one speaker to amplifiers 01901, 14581, 20581?
回答： Yes, in this case you must terminate the unused amplifier channel with a 100 Ohm 1Watt resistance.
