03983
Wiring devices / View Wireless wiring devices / Shared components / Non-modular components
3IN 1OUT IoT connected module
VIEW Wireless electronic module with 3 programmable digital inputs for potential-free contacts, 1 programmable NO/NC relay output for SELV voltage-free contact, IoT technology on Bluetooth 5.0 standard to create the VIEW Wireless mesh system, 100-240 V 50/60 Hz power supply, flush mounting (retrofit)
产品状态
3 - Active
您可能也感兴趣
单, 说明书, 文档
- Light multilanguage instructions sheet (1210 kb)
- Full ورقة الإرشادات (1858 kb)
- Notice technique Full (1780 kb)
- Ficha de instrucciones Full (1778 kb)
- Full instructions sheet (1771 kb)
- Φυλλάδιο οδηγιών Full (1845 kb)
- Anweisungsblatt Full (1779 kb)
- Foglio istruzioni Full (1748 kb)
- Manuale app View Wireless (19692 kb)
- Manual View Wireless app (42576 kb)
- Manuel appli View Wireless (43518 kb)
- Manual app View Wireless (43516 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43799 kb)
- Installationsanleitung View Wireless (43585 kb)
图纸
Class group
Relays
Relays
Class
Switching relay
Switching relay
Type of electric connection
Screw connection
Screw connection
Complete with socket
Yes
Yes
With detachable clamps
No
No
With LED indication
No
No
Voltage type for actuating
AC
AC
Drive, polarization
Polarity free
Polarity free
Degree of protection (IP)
IP20
IP20
Width
55,10 mm
55,10 mm
Height
54,30 mm
54,30 mm
Depth
23,00 mm
23,00 mm
37. Marking - Morocco
40. Bluetooth technology
最小订单数量: 1 NR
条形码
8007352761254
1 NR
6x5.4x5.2 [cm]
49 [g]
8007352761261
60 NR
37.5x30x13.5 [cm]
3,300 [g]
