03985
Wiring devices / View Wireless wiring devices / Shared components / DIN devices
IoT connected multif.actuator 4out relay
VIEW Wireless electronic control actuator with 4 relay outputs 16 A 240 V~, programmable NO/NC with function to control lights, roller shutters with slat orientation, fan coil, climate control, accesses, sprinkler system, push buttons for local control, IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system, 100-240 V 50/60 Hz power supply, installation on DIN rail (60715 TH35), occupies 4 modules size 17.5 mm
产品状态
3 - Active
您可能也感兴趣
单, 说明书, 文档
- Foglio istruzioni Full (491 kb)
- Full instructions sheet (485 kb)
- Ficha de instrucciones Full (488 kb)
- Anweisungsblatt Full (488 kb)
- Light multilanguage instructions sheet (1082 kb)
- ورقة الإرشادات Full (619 kb)
- Notice technique Full (488 kb)
- Φυλλάδιο οδηγιών Full (597 kb)
- Manuel appli View Wireless (42961 kb)
- Manual app View Wireless (42960 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43239 kb)
- Installationsanleitung View Wireless (42993 kb)
- Manuale app View Wireless (19692 kb)
- Manual View Wireless app (42576 kb)
图纸
Class group
Installation bus systems
Installation bus systems
Class
Switch actuator for bus system
Switch actuator for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
Yes
Yes
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
None
None
Radio frequency bidirectional
Yes
Yes
Mounting method
DRA (DIN-rail adaptor)
DRA (DIN-rail adaptor)
Width in number of modular spacings
4
4
Local operation/hand operation
Yes
Yes
With LED indication
Yes
Yes
01. IMQ - Italy
37. Marking - Morocco
40. Bluetooth technology
最小订单数量: 1 NR
条形码
8007352767416
1 NR
11.7x10.8x7.1 [cm]
241.7 [g]
8007352767423
60 NR
59x38.5x30 [cm]
15,225 [g]
