1P 10AX 1-way switch+P30 outlet white - 06696.B

Pdf
Vimar - 06696.B - 1P 10AX 1-way switch+P30 outlet white
Vimar - 06696.B - 1P 10AX 1-way switch+P30 outlet white
06696.B

Mascot / Devices / Devices - other functions

1P 10AX 1-way switch+P30 outlet white
1P 10 AX 250 V~ 1-way switch + 2P+E 16 A 250 V~ SICURY socket outlet, Italian standard P30 (lateral and central earth contacts), white

产品状态
2 - Will be discontinued

您可能也感兴趣

V71001
V71001 - Flush mounting box ø 60mm light blue
V71001.AU
V71001.AU - Flush mounting box ø 60mm light black
V71701
V71701 - Round flush-mount box f/hollow wall blue
Class group
Domestic switching devices
Class
Combination switch/wall socket outlet
Type of switch
Off switch
Type of socket outlet
Other
Number of socket outlets
1
Method of operation
Rocker/button
Mounting direction
Horizontal and vertical
Type of fastening
Mounting with claw
With lighting
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9003
Transparent
No
Suitable for degree of protection (IP)
IP20
Nominal voltage
250 v
Nominal current socket outlet
16 A
Rated current
16 A
Over voltage protection
No
Fault current protection
No
Width of device
80,00 mm
Height of device
80,00 mm
Depth of device
36 mm

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

Barcode Qty 1 NR
8007352095496
1 NR
8x8x3.6 [cm]
87.93 [g]
Barcode Qty 20 NR
8007352095649
20 NR
35.5x24.8x8.7 [cm]
1,983.67 [g]
