1P 16AX 1-way switch 2M white - 09001.2

Pdf

Vimar - 09001.2 - 1P 16AX 1-way switch 2M white

09001.2

Neve Up / Devices / Basic devices

1P 16AX 1-way switch 2M white
1P 16 AX 250 V~ 1-way switch, white - 2 modules. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

09001 - 1P 16AX 1-way switch white

09005.2 - 1P 16AX 2-way switch 2M white

09013.2 - 1P 16AX reversing switch 2M white

09008.2 - 1P NO 10A push button 2M white

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Off switch 1-pole

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
2

Push button switch
Yes

Number of rockers
1

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 v

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Width of device
44,80 mm

Height of device
47,00 mm

Depth of device
35,90 mm

Built-in depth
23,10 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

19. NOM - Mexico

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 20 NR

条形码

8007352296640

1 NR

5.1x4.3x5.3 [cm]

30.8 [g]

8007352296657

20 NR

26.9x11.6x9 [cm]

697.6 [g]

8007352296664

240 NR

37x28x34.5 [cm]

8,913.2 [g]
