1P 16AX 2-way switch white - 09005

Pdf

09005
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P 16AX 2-way switch white
1P 16 AX 250 V~ 2-way switch, white. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

图纸

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
22,30 mm
Device height
47,00 mm
Device depth
35,90 mm
Built-in depth
23,10 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

19. NOM - Mexico

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352296671
1 NR
4.1x2.8x5.3 [cm]
25.8 [g]
Barcode Qty 50 NR
8007352296688
50 NR
21.4x11.6x14.2 [cm]
1,378.8 [g]
Barcode Qty 500 NR
8007352296695
500 NR
57.5x22x29.5 [cm]
14,264 [g]
