2P 10AX switch white - 09060

Pdf

Vimar - 09060 - 2P 10AX switch white

09060
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P 10AX switch white
2-button 2P 10 AX 250 V~ 2-way switch (6 terminals) with directional arrows and central OFF position, white. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

09062 - Two interlocked 1P NO+NO 10A pushes w

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Other

Number of rockers
1

Number of modules (module system)
100

Number of poles
2

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Glossy

Colour
White

RAL-number (similar)
9003

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
47,00 mm

Device depth
43,00 mm

00. CE Marking - EU

07. INGCER - Chile

10. EAC Eurasian Customs Union

13. SNI - Indonesia

19. NOM - Mexico

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352305090

1 NR

5.1x2.8x5.3 [cm]

41.8 [g]

8007352305106

10 NR

14.4x11.6x6 [cm]

461.33 [g]

8007352305113

120 NR

37.5x30x13.5 [cm]

5,942 [g]
