Dimmer MASTER 230V universal carbon matt - 09135.1.CM

Pdf

Vimar - 09135.1.CM - Dimmer MASTER 230V universal carbon matt

09135.1.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Dimmer MASTER 230V universal carbon matt
Universal phase cutting dimmer 230 V~ 50 Hz, for 40-400 W incandescent lamps, 40-300 VA electronic transformers, 10-200 W CFL lamps, 3-200 W LED lamps, for LED phase cutting electronic power supply units, ON/OFF control and regulation by built-in push button or via NO peripheral push buttons, MASTER function for 14137, minimum brightness control, visible in darkness, carbon matt. Device not suiTable for installation in Isoset enclosures

产品状态
3 - Active

您可能也感兴趣

09153.CM - Dimmer 230V 100-500W push-push carbon m

09146.CM - Dimmer 230V 60-900W/60-300VA carbon matt

单, 说明书, 文档

Multilanguage instructions sheet (1734 kb)

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Dimmer

Method of operation
Push button

App control via Bluetooth
No

Type of load
Universal and LED Retrofit

Applicable with button
Yes

Applicable with movement sensor
No

Applicable with presence indicator
No

Applicable with time switch/timer
No

Applicable with transmission button
No

Applicable with infrared button
No

Mounting method
Flush-mounted

Type of fastening
Snapper mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7016

Transparent
No

Nominal voltage
230,00 - 230,01 V

Frequency
50,00 - 50,01 HZ

Control voltage
230,00 - 230,01 V

Device width
22,30 mm

Device height
47,00 mm

Device depth
51,10 mm

00. CE Marking - EU

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352664555

1 NR

5.1x4.3x5.3 [cm]

53.2 [g]

8007352664562

10 NR

26.9x11.6x4.9 [cm]

594.6 [g]

8007352666313

200 NR

47.5x27x29 [cm]

12,208 [g]
