Frame 2M +claws 71mm

Pdf

09602.1
Wiring devices / Traditional wiring devices / NEVE UP / Mounting frames

Frame 2M +claws 71mm
2-module mounting frame, with claws, for flush mounting box ø 60 mm, modular with distance between centres of 71 mm

产品状态
3 - Active

您可能也感兴趣

09603.1 - Frame 2M wihtout screws 71mm

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with claw

With nail
No

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

00. CE Marking - EU

29. QCERT - Colombia

43. UKCA mark - Great Britain

最小订单数量: 50 NR

条形码

8007352657854

1 NR

7.3x7.3x2.5 [cm]

26.46 [g]

8007352657861

50 NR

28.4x24.4x11.9 [cm]

1,208 [g]

8007352657878

300 NR

59.5x38.5x26.5 [cm]

7,938 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
